SIMADRE 5200DX 50A PLASMA CUTTER 200A TIG ARC MMA WELDER with FOOT PEDAL
Simadre 110V/220V SIMCT-5200DX 50 Amp Plasma Cutter / 200 Amp TIG/ARC/MMA Welder
Includes a One Year Warranty!
Simadre brings you the latest in plasma cutter technology with the new SIMCT-5200DX
An affordable high quality machine that performs as well as and in some cases surpasses well known brand name machines at a fraction of the cost
High working efficiency / DC output can cut the same thickness on 110V or 220V!!!
3" Per minute at 1" Steel (Severance Cut)
7" Per minute at 3/4" Thick Steel
17" Per minute at 1/2" Thick Steel
Flexible TIG torch comes with long and short back caps for welding in tight places
Machine is equipped with a large cooling fan and is thermostatically protected for a longer life span
Strong and very reliable - ready for Industrial/Commercial and any other application
Equipped with an advanced inverter technology and high cutting frequency V-MOSFET from TOSHIBA/FUJI.
Certification: CE, CCC, CSA and ISO-9001 certification
Four knobs on front of machine:
Pre-flow time: to adjust the time for air/gas blow out of torch before welding
Current: for welding/cutting current
Down slope: would help to weld stainless steel
Post gas/air time: to adjust the time for air/gas blow out of torch after welding
Package Includes: Plasma Cutter Inverter Unit
Ground Cable& Ground Clamp
High Performance Cutting Torch with initial consumables
TIG Torch with initial consumables
Air Filter / Regulator & Hose
Foot Pedal
Owners manual
Buyer must provide:
Air supply - 4.5 CFM @ 75 PSI
220 or 110 V AC power source & plug
Argon Tank for TIG welding & Argon Regulator
Specifications:
Input voltage
AC 110/220±15% 50/60Hz
Input Power Capacitance 7.1 kva
No-load loss(W) 40
Duty cycle (%) 60
Power factor 0.93
Efficiency (%) 85
Insulation class B
Protection class IP21
Input current(A) 21 32 28.6 (TIG MMA CUT)
Rated output current 200A 200A 50A
Current range 15-200 15-200 20-50
No load voltage(V) 62 62 250
Cut thickness(mm) - - 1-16
Arc-leading HF vibrate Touch HF vibrate
Dimensions:
Unit size: 17 L x 8 W x 12 H
Unit Weight: 29 lbs.
Shipping Weight: 55 lbs.
